4 Camera 4 Channel 5MP Lite 4K Ultra HD DVR Security Camera System Indoor

Features(Not included hard drive):

• (1). [ Smart AI Motion Detection & Alerts push ] __ Experience the advantages of AI-based detection, distinguishing between people and vehicles. Customize motion detection zones for each camera, reducing false alerts from natural movements and ensuring privacy. Receive prompt notifications and email alerts with snapshots whenever motion is detected, providing peace of mind and quick response.
•

• (2). [ 5MP 4K Lite System Overview ] __ Exclusive 4 Channel 4K 5MP-Lite DVR Recorder paired with 4 1080p bullet cameras with 65ft night vision and 90°view angle.

•

• (3). [ Advanced H.265+ High Efficiency Video Compression ] __ Kepeak self-developed H.265+ video coding technology extract features that focus on characteristics of the surveillance scenes for larger storage space and better image quality. H.265+ can further improve compression ratio on the basis of H.265 standard and save about 80% storage compared with H.264, and thus effectively saving storage resources and provides an excellent and smooth viewing experience.
•

• (4). [ Customize Each Camera with Different Record Modes ] __Our Kepeak DVR offers 4 kinds recording modes to meet your needs: Record footage continuously; Record during scheduled times; Only record when detect motion; Recycle record. You can customize each camera with different recording modes, and download the recording files for the USB backup.

Specification:

Camera parameters:
Signal system: XVI/AHD/TVI/CVIS/CVBS
Effective pixels: PAL/NTSC: 1920 * 1080 / 4K
Minimum illumination: Color: 0.1Lux @ (F1.2, AGC ON), 0Lux with IR
Black and White: 0.01Lux @ (F1.2, AGC ON), 0Lux with IR
Photoresistor port: 1 photoresistor port, supporting photoresistor input signals and images, IR-CUT, Linkage of infrared lights
Shutter: 1/50 (1/60) seconds to 1/10000 seconds
Day and night function: supports IR-CUT mechanical switching
Lens parameters: C/CS interface, optional M12 lens
Video output: 1080P@25fps
Power supply: DC12V ± 10%
Working environment: Temperature -10 ℃~60 ℃, humidity less than 90% (no condensation)
Power consumption:<5W
Size: 32mm * 32mm single board (compatible with 38 positioning holes)
Note: Comes with coaxial control as standard, supports coaxial upgrade, and signal switching can be achieved through tail line short circuit/OSD menu
Video recorder parameters:
Screen display: 1/4 screen (taking coaxial input mode as an example, others depend on channel mode)
Monitoring quality: VGA (up to 1080P)/HDMI (up to 1080P)
Multi mode input: coaxial, hybrid, network
Motion detection: 192 (16 * 2) detection areas can be set for each screen
Video recording methods: manual, alarm, dynamic detection, timed
Local playback: 2/4 channels
Video retrieval: time point retrieval, calendar retrieval, event retrieval, channel retrieval
Video storage: local hard drive, network
Video input interface: 4-channel BNC
Video output interface: 1 VGA, 1 HDMI
PTZ control: supports multiple PTZ protocols
USB ports: 2 USB ports
Single camera size: 95 * 85mm

Product Features:

1.24 hours of daily recording is set as the default setting for the factory, and device users can customize the recording schedule;
2. The day and night monitoring set is equipped with 4 full HD wireless cameras;
3. Equipped with multiple functions, such as night vision (up to 65 feet), real-time streaming, remote monitoring, and motion detection alerts;
4. Installation: Using automatic pairing technology, plug the camera and DVR power into nearby sockets, connect the DVR box to the monitor, and smoothly obtain clear and bright images during the day or night;
5. Remote monitoring and playback: Free applications can be downloaded for remote viewing and playback of recordings (ensuring that the DVR is connected to the router via an Ethernet cable).


Package include:
4 * Camera
1 * DVR
4 * Camera BNC extension cable
1 * Mouse
1 * Video recorder power supply
1 * Camera power supply
1 * 4 in 1 DC power splitter line
